SAVA Low Pressure Lifting Bag

Low-pressure lifting bags are used for lifting very large objects. They have special Top Grip pads bonded to the top and bottom of the bag.

Top Grip pad offers heavy duty protection from slipping, puncture, abrasion and premature wear. Used for uprighting trucks, rail cars, and other types of vehicles or structures.

Key features & benefits

  • Lifting height up to 2.1 m
  • Ideal for towing recovery
  • Special TOP GRIP pads
  • Use on all grounds (rock, glass, metal)
Technical Data
TYPE PART NUMBER DIMENSIONS WEIGHT NOMINAL
CONTENT		 MAX LIFTING
CAPACITY		 MAX. LIFTING
HEIGHT
DIAMETER HEIGHT
[cm] / [inch] [cm] / [inch] [kg] / [lbs] [l] / [cu./Ft.] [t] / [US Tons] [cm] / [inch]
MS 45 527296 102 / 40″ 10 / 4″ 16 / 35 368 / 13 4 / 4.4 45 / 18
MS 122 527297 135 / 53″ 10 / 4″ 30 / 66 1745 / 62 7 / 7.7 122 / 48
MS 210 527298 145 / 57″ 10 / 4″ 43 / 95 3466 / 122 9 / 9.9 210 / 83
